Overview
■ Provides 5…1250 A range
■ Uses rated voltage: 200…690V AC, 50/60 Hz
■ Includes nine start and stop modes
■ Includes three slow-speed modes
■ Offers pump control and braking control options
■ Provides built-in electronic motor overload protection
■ Provides built-in silicon-controlled rectifier (SCR) bypass/run contactor
■ Provides built-in multi-lingual, backlit LCD display for programming and monitoring
■ Offers optional communication modules support multiple networks
■ Programming via Connected Components Workbench™ software
■ Users who would like to take advantage of the additional functionality of SMC-50 soft starters, now have access to an internal bypass on that product line. Also, kits are now available to upgrade certain sizes of SMC-Flex controller to SMC-50 functionality. For information on selecting the appropriate SMC-50 to meet your current SMC-Flex application see the SMC Flex to SMC-50 With Internal Bypass Migration Solutions Profile
■ This product is designed for many applications that include compressors, chillers, pumps, conveyors, and crushers
